Irf2807 Mosfet-n 75v 82a To-220ab
$ 9.000
Irf2807 Mosfet-n 75v 82a To-220ab
*************************************************************************************************************************************************************
Manufacturer: Infineon
Product Category: MOSFET
Technology: Si
Mounting Style: Through Hole
Package / Case: TO-220-3
Number of Channels: 1 Channel
Transistor Polarity: N-Channel
Vds – Drain-Source Breakdown Voltage: 80 V
Id – Continuous Drain Current: 82 A
Rds On – Drain-Source Resistance: 13 mOhms
Vgs – Gate-Source Voltage: 20 V
Minimum Operating Temperature: – 55 C
Maximum Operating Temperature: + 175 C
Configuration: Single
Pd – Power Dissipation: 230 W
Channel Mode: Enhancement
Height: 15.65 mm
Length: 10 mm
Transistor Type: 1 N-Channel
Width: 4.4 mm
Brand: Infineon / IR
Fall Time: 48 ns
Rise Time: 64 ns
Typical Turn-Off Delay Time: 49 ns
Typical Turn-On Delay Time: 13 ns
Unit Weight: 6 g
*************************************************************************************************************************************************************
